Cannon Scupper by Grand Effects
Made with the highest quality construction and materials the Cannon Scupper by Grand Effects is available in Oil Rubbed Hammered Copper, Brushed Stainless Steel, and Brushed Copper.
The cannon scupper also comes in 4 amazing powder-coated metal finishes.
Choose from 3 different width sizes 1.5", 2", 3" to best suit your design.
Important:
- Stainless Steel is not suitable for Salt-water Applications
- Due to natural properties, copper material tends to develop a greenish blue hue when exposed to several natural elements.
Note: Bobe Water and Fire products now available by Grand Effects
Grand Effects is now offering the most popular Bobe Fire and Water products.
Old Bobe product: Bobe Water & Fire Cannon Scupper (CS-1.5)
New Grand Effects product: Cannon Scupper by Grand Effects. (CSC-1.5)
| Size |
1.5" |
2" |
3" |
| Brushed Copper |
CSC-1.5 |
CSC-2 |
CSC-3 |
| Brushed Stainless Steel |
CSS-1.5 |
CSS-2 |
CSS-3 |
| Powder Coated Colors |
Black - BLK
Bronze - BNZ
Chestnut Hammertone - CH
Grey Hammertone - GH |
Product Features:
- Constructed with heavy gauge materials
- Available in Copper, Hammered Copper & Stainless Steel.
- All seams are fully welded and fully polished
- No filter or rock trap is needed; Scuppers are designed to never clog
- Equipped with a 1.5" back female inlet and includes a bonding lug for a solid install
Cannon Scupper Specifications:
| Choose form Width sizes |
1.5", 2", 3" |
| Dimensions: Length x Height |
12" Length x 5" Height |
| Connection |
1.5" Female Inlet
|
| Flow Rate |
15-20 Gallons Per Minute //FT
|
| Material |
Copper, Stainless Steel, Hammered copper and 4 Powder-coated metal finishes.
|
| Bonding Lug |
Bonding lug located next to the inlet
|
| Inlet |
Back or Bottom options for a 1.5” female inlet
|
Specifications:
- E = 1.5", 2" or 3" Scupper Width sizes available.
- 12" Scupper Length which remains constant for all width sizes
- Baffle Chamber:
- 5" Height x 5" Width which remains constant for all sizes
- 3" Length which remains constant for all sizes
Need the Scupper with Custom Dimensions?
Please download and fill out the Custom Scupper form with the desired dimensions and information. Please email the filled form to us at info@MajesticFountains.com. We will send you a quote. Upon approval of the quote and payment, custom scupper will be manufactured to requested dimensions (Custom products are not returnable).
Custom Scuppers have a manufacturing lead time of approximately 3 weeks.
Cannon Scupper - Custom Order Form
Documents:
Grand Effects Scupper Installation Manual
Manufacturing Lead Time: 2-3 weeks. Powder-coated products require an additional one-week lead time.
Shipping: We offer Free standard curbside shipping on this product to the 48 lower contiguous states.
WARRANTY: 1 Year Limited Warranty - For Manufacturer Defects.
